Model No : AQM-9XX
Real-Time Air Quality Monitoring Solution for Construction Sites & Environmental Compliance manufacturer, supplier, and exporter, Mumbai-India.
The BMC Approved Air Quality Monitoring (AQM) System – AQM-9XX is a compact and reliable environmental monitoring solution designed for continuous real-time monitoring of critical air quality and meteorological parameters in accordance with municipal environmental monitoring requirements.
The system consists of a dedicated Outdoor LED Display Unit and an independent Data Logger Unit, ensuring reliable real-time visualization, secure data storage, and long-term performance in outdoor environments. Designed specifically for construction sites, infrastructure projects, demolition activities, and municipal compliance applications, the AQM-9XX provides accurate measurement of particulate matter and weather parameters while enabling continuous environmental monitoring and reporting.
Monitored Parameters
Air Quality Parameters
- PM₁₀ (Particulate Matter ≤10 µm)
- PM₂.₅ (Particulate Matter ≤2.5 µm)
Meteorological Parameters
- Ambient Temperature
- Relative Humidity
How It Works
The AQM-9XX continuously measures ambient particulate matter concentrations and weather conditions through dedicated sensors. The collected data is processed by the integrated data logger and instantly displayed on the outdoor LED display for public visibility and regulatory compliance.
All monitoring data is automatically stored within the data logger and can be accessed through RS-485 communication and the built-in Wi-Fi hotspot. Historical records are retained for long-term analysis, reporting, and compliance verification.
Key Features
Real-Time Monitoring
Continuous monitoring and display of PM₁₀, PM₂.₅, Temperature, and Humidity with instant data updates.
Outdoor Industrial LED Display
High-brightness LED display designed for outdoor visibility with viewing distance up to 50–100 meters.
Separate Display & Data Logger Units
Independent display and data logging architecture ensures reliable operation, flexible installation, and secure data management.
Long-Term Data Storage
Built-in data logger with SD card support capable of storing monitoring data for up to 3–4 years depending on logging interval and storage capacity.
Wi-Fi Hotspot Connectivity
Integrated hotspot functionality enables local access for configuration, diagnostics, and data retrieval without requiring additional communication infrastructure.
RS-485 Communication
Supports Modbus RTU communication over RS-485 for reliable sensor integration and data collection.
Historical Data Retrieval
Stored monitoring records can be easily accessed for environmental reporting, audits, and compliance verification.
IP65 Weatherproof Design
Designed for outdoor operation with protection against dust, rain, humidity, and harsh environmental conditions.
Low Maintenance Operation
Industrial-grade design ensures reliable performance with minimal maintenance requirements.
Technical Specifications
| Parameter | Specification |
|---|---|
| Display Type | Outdoor Industrial LED Display |
| Display Parameters | PM₁₀, PM₂.₅, Temperature, Humidity |
| Visibility | 50–100 meters |
| Brightness | Auto-adjustable High-Brightness LEDs |
| Display Format | Real-Time Scrolling / Static Display |
| Character Height | 4"–6" (Customizable) |
| Communication Interface | RS-485 / Ethernet |
| Communication Protocol | Modbus RTU over RS-485 |
| Power Supply | 230 VAC, 50 Hz |
| Enclosure Material | Powder-Coated MS / Aluminum |
| Protection Class | IP65 Weatherproof |
| Operating Temperature | -10°C to +60°C |
| Mounting Type | Pole Mounted / Wall Mounted |
| Data Refresh Rate | Real-Time (User Configurable) |
| Data Retention | Up to 3–4 Years |
| Historical Data Retrieval | Available |
| Weather Resistance | Yes |
| Maintenance | Low Maintenance Design |
Communication Features
- Construction Site Monitoring
- Infrastructure Development Projects
- Demolition Site Monitoring
- Smart City Projects
- Municipal Environmental Compliance
- Urban Air Quality Monitoring
- Road & Highway Construction Projects
- Commercial & Residential Development Projects
- Industrial Environmental Monitoring
Benefits
Regulatory Compliance
Helps construction and infrastructure projects comply with BMC environmental monitoring requirements.
Public Awareness
Real-time display of air quality parameters enhances transparency and public awareness regarding environmental conditions.
Reliable Data Management
Long-term data storage and historical retrieval simplify compliance reporting and environmental audits.
Easy Installation
Compact architecture with separate display and data logger units allows flexible deployment in various site conditions.
Robust Outdoor Performance
IP65-rated enclosure and industrial-grade components ensure reliable operation in challenging weather conditions.
Why Choose AQM-9XX?
The AQM-9XX combines accurate particulate monitoring, real-time public display, long-term data storage, and reliable communication capabilities into a compact and rugged platform. Designed specifically for BMC-approved environmental monitoring applications, it provides a dependable and cost-effective solution for construction site compliance and ambient air quality monitoring.
Proudly Developed in India
Designed, developed, and manufactured by Instrumex, the AQM-9XX reflects our commitment to innovation, quality, and customer satisfaction. Built to meet the demands of Indian environmental conditions, it delivers reliable performance, comprehensive data management, and dependable service support.
