Model No : GA607

Noise Calibrator / Sound Calibrator manufacturer, supplier, and exporter, Mumbai-India.

The GA607 meets the demanding standards of a class 1 calibrator. It features two calibration levels, 94dB and 104dB re 20μPa both at 1kHz. It is for use with 1/2" microphones. Using the GA607, a sound level meter can be checked at two meter scale points and usually on two ranges. Supplied with GA690 barometer

Key Features

  • Dual Level - 94dB & 104dB relative to 20μPa
  • Built to the requirements of IEC60942:2003 Sound Calibrators
  • Class 1/C.
  • It is supplied with a ½" cavity.

Product Specifications

  • Nominal Sound Pressure level at 101.3kPa (760mm Hg), 23º & 50%RH.
  • Tolerance: ± 0.3dB.
  • Harmonic Distortion: < 3% .
  • Temperature range: -10°C to 50ºC.
  • Batteries: 2 x3V CR2032 (Coin Cell).
  • Life: approx. 70 hours.
  • Cavity diameter: ½" microphone Standard
  • Dimensions: Length: 140mm, Diameter: 51mm, Weight: 230gms.

GA690 Barometer

IEC 60942 states that for a calibrator to be used in the Class 1 category, it must be corrected for barometric pressure. The Castle GA690 barometer is supplied with the GA607 Class 1/C calibrator for just this purpose. With a simple readout on the clear display and a correction table printed on the reverse, this is a simple process.

Technical Specifications

GA690 Specifications
Frequency Range 0 to 1300mbar (0 to 975mmHg)
Resolution 1mbar, 1mmHg
Accuracy ±0.25% FS hysteresis and linearity
Battery 9V Alkaline type 6LR61 (PP3)
Battery life Greater than 2500 hours
Dimensions 106 x 67 x 30mm (LxWxH)
Weight 135g incl. battery
