Model No : IPM-971
INSTRUMEX Portable Air / VOC Sampler manufacturer, supplier, and exporter, Mumbai-India.
The INSTRUMEX Portable Air / VOC Sampler (Model: IPM-971) is a compact, lightweight, and versatile air sampling instrument designed for the collection of airborne particulate matter, gaseous pollutants, volatile organic compounds (VOCs), and workplace contaminants. Developed and manufactured by Instrumex, the IPM-971 is ideal for industrial hygiene studies, indoor air quality assessments, personal exposure monitoring, and environmental investigations.
With its rechargeable battery operation, programmable timer, and multiple flow range options, the IPM-971 provides reliable and flexible sampling for both field and laboratory applications. Its rugged diaphragm pump ensures continuous operation without overheating, making it suitable for demanding workplace and outdoor environments.
How It Works
The IPM-971 draws air through a selected sampling media using a precision-controlled diaphragm pump. Depending on the application, the sampler can be connected to filter holders, impingers, activated charcoal tubes, or other sampling accessories.
Particulate matter is collected on filter papers, gaseous pollutants are absorbed in impinger solutions, and VOCs or solvent vapors are captured using activated charcoal tubes for subsequent laboratory analysis. The programmable timer allows automatic start and stop operation, while pulse mode enables intermittent sampling for extended monitoring periods.
The rechargeable lithium-ion battery and inbuilt charging circuit allow uninterrupted sampling both on battery power and while connected to AC mains.
Key Features
- Compact and lightweight design (less than 1 kg)
- Extremely portable and ultra-quiet operation
- Simultaneous sampling of dust and gaseous pollutants
- Multiple flow range options:
- 0–5 LPM (handy dust sampler)
- 0–500 mLPM (VOC sampler)
- 0–200 mLPM (VOC sampler)
- Precision flow adjustment using needle valve
- Rechargeable Lithium-Ion battery
- Up to 7–10 hours continuous battery operation
- Digital programmable timer
- Automatic start and stop functionality
- Pulse mode operation for intermittent sampling
- Rugged diaphragm pump for continuous duty operation
- Inbuilt battery charging circuit
- AC and battery-powered operation
- Portable design suitable for indoor and outdoor applications
Sampling Accessories Supported
Filter Paper Sampling
- Acrylic filter holder for:
- 25 mm filter papers
- 47 mm filter papers
- Suitable for dust and particulate matter sampling
Gaseous Pollutant Sampling
- Provision for 2 Nos. borosilicate glass midget impingers (35 mL capacity)
- Suitable for collection of:
- SO₂
- NOx
- NH₃
- Other inorganic gases
VOC & Solvent Vapor Sampling
- Compatible with activated charcoal tubes
- Suitable for:
- VOC monitoring
- Hydrocarbon sampling
- Solvent vapor analysis
- Occupational exposure studies
Benefits
Portable Monitoring Solution
Its lightweight and compact design allows easy transportation and deployment in workplaces, industrial facilities, laboratories, and field locations.
Versatile Sampling Capabilities
The sampler supports dust, gas, and VOC sampling using a single instrument, reducing equipment requirements and operational costs.
Personal Exposure Monitoring
The compact size and battery-powered operation make it ideal for worker exposure assessment and occupational hygiene studies.
Long Operating Duration
Rechargeable battery operation and pulse sampling mode provide extended sampling capability for long-duration monitoring programs.
Reliable Performance
The rugged diaphragm pump ensures stable operation and accurate sample collection even in challenging environmental conditions.
Applications
- Industrial Hygiene Studies
- Personal Exposure Monitoring
- Indoor Air Quality Assessment
- VOC Monitoring
- Occupational Health & Safety Programs
- Environmental Monitoring
- Workplace Air Quality Surveys
- Solvent Vapor Monitoring
- Hydrocarbon Sampling
- Laboratory Research Applications
- Industrial Process Monitoring
- Environmental Impact Studies
Why It Helps
Airborne contaminants such as dust, gases, and volatile organic compounds can significantly affect worker health, safety, and environmental quality. Accurate sampling is essential for identifying exposure risks, evaluating control measures, and ensuring regulatory compliance.
The INSTRUMEX IPM-971 Portable Air / VOC Sampler provides a convenient and reliable solution for collecting representative air samples for laboratory analysis, helping organizations assess air quality, protect worker health, and improve environmental performance.
Proudly Developed in India
Designed and manufactured in India, the INSTRUMEX IPM-971 combines portability, reliability, and versatility in a compact package. With its advanced features and robust construction, it is an ideal solution for professionals involved in industrial hygiene, occupational safety, environmental monitoring, and air quality assessment.
