Model No : IPM-COD-321
Advanced Water & Wastewater Analysis Solution for Rapid COD Measurement manufacturer, supplier, and exporter, Mumbai-India.
The INSTRUMEX COD Analyzer (Model: IPM-COD-321) is a high-performance spectrophotometric instrument designed for the rapid and accurate determination of Chemical Oxygen Demand (COD) in water and wastewater samples. Utilizing the proven dichromate digestion colorimetric method, the analyzer delivers reliable and precise results within minutes, making it an ideal solution for environmental laboratories, wastewater treatment plants (WWTP), sewage treatment plants (STP), industrial effluent monitoring, research institutions, and regulatory compliance applications.
The system combines advanced UV-Visible spectrophotometric technology with a user-friendly interface, enabling fast, accurate, and repeatable analysis of COD and other water quality parameters while ensuring reliable performance for routine laboratory testing and environmental monitoring.
Applications
- Wastewater Treatment Plants (WWTP)
- Sewage Treatment Plants (STP)
- Effluent Treatment Plants (ETP)
- Industrial Wastewater Monitoring
- Environmental Testing Laboratories
- Municipal Water Quality Monitoring
- Pharmaceutical Industries
- Chemical Industries
- Food & Beverage Industries
- Research & Academic Institutions
- Environmental Compliance Monitoring
Parameters Measured
Standard Parameters
- Chemical Oxygen Demand (COD)
- Biochemical Oxygen Demand (BOD)
- CODMn (Permanganate Index)
- Ammonia Nitrogen (NH₃-N)
- Total Nitrogen (TN)
- Total Phosphorus (TP)
Additional Parameters
- Nitrate
- Nitrite
- Chlorine
- Sulphate
- Fluoride
- Iron
- Chromium
- Copper
- Zinc
- Manganese
(30+ Water Quality Parameters Depending on Reagent Configuration)
How It Works
The IPM-COD-321 utilizes the dichromate digestion colorimetric method, where the water sample is digested using pre-prepared reagent vials under controlled temperature conditions.
During digestion, oxidizable organic matter present in the sample reacts with potassium dichromate. After digestion, the analyzer measures the absorbance of the sample using dual-wavelength UV-Visible spectrophotometry.
The instrument automatically calculates and displays the COD concentration based on pre-programmed calibration curves, ensuring accurate, reliable, and repeatable analytical results.
Key Features
Rapid COD Analysis
Provides fast and accurate Chemical Oxygen Demand measurements for routine laboratory testing.
UV-Visible Spectrophotometry
Advanced optical system ensures high precision and repeatable analytical results.
Wide COD Measurement Range
Measures COD concentrations from 2 mg/L to 15,000 mg/L, depending on reagent selection.
Pre-Programmed Test Methods
Built-in calibration curves for COD, BOD, CODMn, ammonia nitrogen, total nitrogen, and numerous other parameters.
Dual Wavelength Technology
Uses 420 nm and 610 nm wavelengths for improved analytical accuracy.
Large Touchscreen Display
User-friendly color touchscreen interface for easy operation and data review.
Integrated Data Management
Stores test results and analytical records for future retrieval and reporting.
Built-In Printer Support
Allows direct printing of test reports and analytical data.
USB & RS232 Connectivity
Supports data transfer and integration with external devices.
High Accuracy Measurement
Provides reliable results with excellent repeatability for laboratory and industrial applications.
Multi-Parameter Capability
One instrument supports analysis of multiple water quality parameters.
Easy Operation
Menu-driven software simplifies testing procedures and minimizes operator errors.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model No. | IPM-COD-321 |
| Measurement Method | Dichromate Colorimetric Method |
| Optical Principle | UV-Visible Spectrophotometry |
| COD Range | 2 – 15,000 mg/L |
| Wavelength | 420 nm & 610 nm |
| Accuracy | ±5% of Reading |
| Sample Volume | 2.5 mL |
| Display | Color LCD Touchscreen |
| Data Storage | Internal Memory |
| Communication | USB, RS232 |
| Power Supply | 220V AC, 50Hz |
| Compliance | APHA / ISO Standard Methods |
Optional Accessories
- COD Reagent Vials
- CODMn Reagent Vials
- BOD Analysis Reagents
- Ammonia Nitrogen Reagents
- Total Nitrogen Reagents
- Total Phosphorus Reagents
- Digital Thermostatic Reactor / Digester Block
- Portable COD Analysis Kit
- Calibration Standards
Benefits
Fast Laboratory Results
Reduces testing time and improves laboratory productivity.
Accurate Water Quality Assessment
Provides reliable COD measurements for environmental monitoring and compliance.
Simplified Operation
Pre-programmed methods eliminate complex calculations and reduce operator dependency.
Regulatory Compliance
Supports water quality monitoring programs following recognized analytical methods.
Cost-Effective Analysis
Multi-parameter capability reduces the need for multiple instruments.
Reliable Data Management
Integrated storage and communication features simplify reporting and record keeping.
Why Choose INSTRUMEX IPM-COD-321?
The INSTRUMEX COD Analyzer combines advanced UV-Visible spectrophotometric technology, user-friendly operation, and multi-parameter testing capabilities into a compact and reliable platform. Designed for modern laboratories and industrial facilities, it delivers fast, accurate, and dependable water quality analysis.
Proudly Developed in India
Backed by Instrumex's expertise in environmental and analytical instrumentation, the IPM-COD-321 provides reliable performance, technical support, calibration assistance, and long-term operational value for water quality monitoring applications.
